System Architecture of WebGIS DataLinq

Overview

WebGIS DataLinq is based on a modular architecture that enables efficient querying, processing, and visualization of data. The main components of the system consist of the web access point (WWW), the DataLinq API, the DataLinq Razor Engine, the DataLinq Code API, and the separate DataLinq Code application for managing endpoints, queries, and views.

_images/DataLinqSysA.png

Architecture Components

WWW – External Requests

The system receives external requests via the WWW. These requests can be of two different types:

  • SELECT requests: request raw data in JSON format.

  • REPORT requests: request formatted HTML reports.

DataLinq API

The DataLinq API forms the central element of the architecture and handles the following tasks:

  • Receiving and processing requests

  • Providing data sources (endpoints), queries, and views

  • Storing and managing configurations in the storage system (file-based)

  • Rendering HTML results via the DataLinq Razor Engine

Storage

The storage system is a file store that manages the following configuration data:

  • Endpoints (data source definitions)

  • Queries (data queries)

  • Views (presentation options)

This structure enables simple management and fast reuse of queries and presentations.

DataLinq Razor Engine

The DataLinq Razor Engine is integrated into the DataLinq API and handles the processing of REPORT requests. It:

  • Renders the Razor-based HTML pages

  • Converts the data from the queries into a formatted presentation

  • Creates interactive visualizations and reports

DataLinq Code API & DataLinq Code

The DataLinq Code API serves as the interface between the DataLinq API and a separate DataLinq Code application, which acts as an editor. These components allow users to adjust the system configuration:

  • DataLinq Code offers a graphical interface for creating and editing endpoints, queries, and views.

  • The DataLinq Code API accepts these configuration changes and stores them in the storage system.

Summary of the Data Flow

  1. WWW sends SELECT or REPORT requests to the DataLinq API.

  2. The DataLinq API processes the request:

    • SELECT requests return JSON data.

    • REPORT requests are rendered by the DataLinq Razor Engine and returned as HTML.

  3. Users manage endpoints, queries, and views via DataLinq Code, with the DataLinq Code API storing these changes.
